The ECUHELP KT200II ECU Programmer has been successfully tested and verified to read and write the Volvo 2.4 D5 EDC16C31 ECU in Bench mode.
Connection Setup:
Use the KT200II multifunction cable together with the BenchBox to establish the bench connection.
Wiring reference:
Software Operation:
In the KT200II software, select the following driver path to perform read and write operations:
→ BENCH MODE
→ Volvo
→ MPC561/2 – Volvo
→ EDC16 C31
Software selection reference:
